Presence

When the message contains a Presence payload, the value Presence will be in the deviceType field of the uplink request.

{ "battery": 100, "daylight": "dark", "presence": true, }

Field

Type

Conditional

Description

Notes

battery

int

No

The remaining battery as a percentage.

daylight

string

Yes

The current light state.

Possible values: light, dark.

presence

boolean

No

If a presence has been detected.

Devices

Desk

DEVICE

Measurement

Supported

battery

Yes

daylight

No

presence

Yes

Presence

DEVICE

Measurement

Supported

battery

Yes

daylight

Yes

presence

yes
